LCR-P1 Capacitor Tester, Mosfet Transistor Tester, Diode Triode Zener Diode Resistance Inductance LCR Meter, MOS NPN PNP E SR Meter, SMD Electronic Component Tester, Battery Test Multimeter
Product details
| Management number | 220422581 | Release Date | 2026/05/03 | List Price | US$13.67 | Model Number | 220422581 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
LCR-P1 Transistor Tester is intended for detecting and analyzing the performance and characteristics of semiconductor components such as transistors, diodes, triodes, and field-effect transistors (FETs), high-precision and multifunctional, designed specifically for electronic engineers, technicians, and enthusiasts.Equipped with a color screen, it allows for multi-parameter measurement of various components, automatically identifies the type and pin arrangement of the tested component, simplifying the operation process and enhancing testing efficiency.Component Test ParametersTransistor: 10 Diode: Forward voltage drop <4.5VVoltage Regulator Diode:0.01-4.5V, 0.01-32VField-Effect Transistor: JFET, IGBT, MIOSTETUnidirectional/Bidirectional SCR: Turn-on voltage <5V, gate trigger current <6mACapacitor: 25μF-100mFResistor: 0.01Ω-50МΩInductor: 10μH-1000μHBattery: 0.1-4.5VInfrared Decoding: NEC protocol infrared codeSPECIFICATIONModel: LCR-P1Display Screen: 1.44”Battery Capacity: 300mAh lithium batterySize: 2.8x3.4x1.1 inPACKAGE1 x LCR-P1 Transistor Capacitor Tester1 x Test Board3 x Test Hook1 x Data Cable1 x User Manual
- Transistor capacitor can measure and analyze the patch component, NPN, PNP, triode, MOS, field effect transistor (FET), diode, Zener diode, capacitor, resistor, inductor, battery, etc
- LCR meter equipped with 2 interchangeable test seats, adaptable for measuring both tiny precision components and high-power devices, simply plug and clamp, one button to quickly and automatically identify the component
- Multimeter transistor capacitor tester features a safe anti-burn protection to automatically discharge undischarged capacitors upon insertion to prevent accidental burning
- Diode Triode resistance inductance LCR meter features 1.44” full-color screen, ultra thin and mini palm size, rechargeable and portable, support of data transmission and firmware upgrade
- MOS NPN PNP E SR meter supports NEC infrared signal decoding for easy testing and maintenance of remote control equipment
- Transistor capacitor tester has an independent measurement channel for measuring diodes, 0.01-32V with pre-measurement power supply for precise results
| UPC | 768825107723 |
|---|---|
| Color | multi |
| Model | 7977-LCR-P1 |
| Brand Name | RQG |
| Style Name | LCR-P1 Transistor Capacitor Tester Meter |
| Unit Count | 1.0 Count |
| Part Number | 7977-LCR-P1 |
| Manufacturer | RQG |
| Power Source | Battery Powered |
| Specification Met | CE, RoHS |
| Included Components | LCR-P1 Transistor Capacitor Tester, Test Board, 3 Test Hooks, Data Cable, Manual |
| Minimum Operating Voltage | 0.01 Volts (DC) |
